ST series SCARA is a planar joint robot developed by Atomrobot for high-speed and high-precision sorting. It has four degrees of freedom in three directions: translation XYZ and rotation around the Z axis.

The robot arm and reducer adopt an integrated design and a unique tooth shape. While providing large load and high speed support, it greatly reduces the size of the robot arm. With the use of high-speed motors, the speed can reach up to 220ppm, and the repeatability accuracy is ±0.02mm; The robot body adopts internal wiring, strong integration, and the protection level can reach up to IP65.
